Product Description
Mechanical Hub Puller – 5 Leg
The Sykes Pickavant Hub Puller range comprises of a wide variety of puller types, all using interchangeable components – whether Hydraulic, Impact or Mechanical, all parts can be used in more than one format, thus providing flexible pulling options and value for money.
Can be used on a variety of wheel stud pattern applications – 4, 5, 6 stud hubs, with a pitch circle up to 203mm
Can be used in 3, 4 or 5 leg combinations
Heavy duty force screw included
Supplied in steel storage case
Can be used with a slide hammer (08520900*) for greater impact force or 1500 Series Ram
Specification
Leg reach: 160 mm
Spread capacity: 100-180 mm
Stud hole diameter: 18mm
Impact screw / hydraulic ram thread: 1.1/2″ BSW
Puller plate thread 1.1/2″ BSW
*will require adaptor 08531270
